Adopt Xinchai engine, with large power reserve, low fuel consumption, more energy saving and environmental protection.
The whole system is equipped with TB chassis, 12+12 shuttle shift, the operation is more convenient and flexible.
Bearings using imported replacement bearings, gear speed ratio scientific collocation, longer service life.
Equipped with double-acting clutch, the power output torque is large, and it is more suitable for heavy duty operation.
Self-developed bionic streamline hood, built-in hood lock, self-developed lens headlight, higher brightness.
The whole tractor covering parts and welded sheet metal parts adopt electrophoretic spraying process, which has better rust prevention effect and is not easy to rust.
Equipped with strong lift strong drop device , two sets of hydraulic output (optional three sets), to ensure that meet the needs of various working conditions,
Optional air-conditioned cab or sunshade to ensure a more comfortable working environment in winter and summer.
|
1 |
Engine |
Engine |
Xinchai |
|
Power |
45HP-75HP |
||
|
Rated speed |
2400r/min |
||
|
Number of cylinders |
4 |
||
|
2 |
Transmission system |
Gearbox |
12F+12R |
|
Main clutch |
Double-acting clutch |
||
|
PTO |
Mechanical control |
||
|
Differential lock |
Machinery |
||
|
PTO shaft speed |
540/1000rpm |
||
|
No of PTO spline |
6 |
||
|
3 |
Front hood |
New engine hood |
Red/Blue |
|
4 |
Drive system |
F/R adjustable steering |
● |
|
Front axle |
● |
||
|
Tyre |
8.3-20/12.4-28 |
||
|
Rim color |
Sliver |
||
|
Edge valve protection |
● |
||
|
Rim color |
Mechanical control |
||
|
Service brakes |
Mechanical control |
||
|
5 |
Hydraulic system |
Oil joint construction |
● |
|
Double auxiliary cylinders |
● |
||
|
Hydraulic output |
2 Group |
||
|
Category |
Ⅱ |
||
|
6 |
Counterweight |
Front |
● |
|
Rear |
● |
||
|
7 |
Electrical system |
Instrument cluster |
● |
|
Maintenance-free battery |
● |
||
|
LED working lights |
● |
||
|
Rotatory warning lights |
● |
||
|
8 |
Fuel tank |
capacity |
60L |
|
9 |
Speed |
Maximum speed |
32KM/H |
|
10 |
Steering |
Hydraulic steering |
● |
|
11 |
Dimension |
weight |
2600kg |
|
Dimensions (LxWxH) |
4190x1790x2690mm |
||
|
Wheel base |
2090mm |
||
|
Wheel track |
1200mm,1300mm |
||
|
Minimum ground clearance |
370mm |







| 504D | TE | TB | TD | TF | TC | TS | |
|
Power (HP) |
25-50 |
50-70 |
50-100 |
100-160 |
180 |
200 |
240-260 |
|
Gearbox |
8F+8R |
8F+8R |
12F+12R |
16F+8R |
16F+8R |
24F+8R |
16F+16R |
|
Weight (kg) |
1500 |
1800 |
2600 |
4800 |
5280 |
6380 |
7800 |
|
Length (mm) |
3150 |
3595 |
4190 |
5050 |
5050 |
5385 |
5580 |
|
Width (mm) |
1400 |
1500 |
1790 |
2250 |
2250 |
2400 |
2550 |
|
Height (mm) |
2170 |
2330 |
2690 |
3050 |
3050 |
3200 |
3200 |
|
Wheel base (mm) |
1065 |
1970 |
2090 |
2500 |
2630 |
2800 |
2880 |
|
Wheel track (mm) |
1050 |
1200 |
1300 |
1600 |
1790 |
1850 |
2050 |
